Parameter Category | Parameterltem | Unit | TypicalValue | Remarks |
Electical
Parameters | BatteryType | | Lithium lron Phosphate
(LFePQ) | High safety,long cycle lie,suitable for industrial and commercia long-term
operafion |
| NominalVoltage | V | 768 | 225S~292Sseries design,compstible with mainsream PCS |
| Nominal Capacity | Ah | 3.2V/280 | Capacityretertion rate ≥95%under confinuous 1C dischargerate |
| Rated Energy | kWh | 215 | Customizable: 215kWh/241kWh/261kWh |
| Charge/Discharge Rate | C | 0.5C(Standard)/1C(Peak) | Peak dischare duration s120min,meefing
peak shaving demand |
| System Effcienay | % | 288(Overall)/298.5
(PCS) | Understandard working condifions(25℃,
0.5Ccharge/discharge) |
Mechanical
Parameters | Cabinet Dimension
(W×D×H) | mm | 1600x1280x2210mm (customizable) | Standard outdor cabinetdesign,suitable
for parallelinstallafion |
| Cabinet weight | t | 2.5 | Depends onenergycapacity and interna
configurafion |
| InstalationType | - | Outdoor Ground
Installation | Fived installafion,compstible with concrete
foundation |
Performance
Parameters | CycleLife(80%DOD) | Cycles | ≥6000 | Capacity retertion ≥80%after cycling.
meefing industial service Iife requirements |
| Monthly Sel-Discharge
Rate | %/Month | ≤3 | Under normaltemperature storage at -30℃-55℃ |
| Operafing Temperature
Range | ℃ | -20~55 | Inteligentliquid coling,adaptive to harsh outdoor environment |
| Communication Protool | | Modbus/104/MQTT | Supports remote monitoning and mulfi-
cabinet centralized management |
