Product Highlights(Core Simplified)
①Excellent Conductivity: Foil-wound structure with oxygen-free copper foil, low DC resistance, small current loss, and efficient energy transmission, suitable for low-voltage operation of oil-immersed transformers
②Stable Insulation Performance: Matching oil-immersed insulation design, combined with insulating paper and transformer oil, good oil permeability, strong breakdown resistance, and safe operation under oil-immersed working conditions
③Compact Structure: Foil-wound integral molding, small volume, high space utilization, tight winding, no loose phenomenon, and strong resistance to short-circuit impact
④Oil-Immersed Adaptation: Special structural design, good compatibility with transformer oil, no deformation or aging in long-term oil-immersed environment, long service life ≥25 years
⑤Easy Processing & Matching: Standardized production, customiz able specifications, perfect matching with various oil-immersed transformers, convenient assembly and later maintenance
Product Details
Core Parameters | Specifications(Core Model) |
Coil Material | Conductor:Oxygen-Free Copper Foil(Thickness 0.1~0.3mm),Insulation: Insulating Paper+Transformer Oil Adaptation |
Winding Process | Foil Winding,Interlayer Insulation Winding,Integral Molding,Suitable for Oil-Immersed Environment |
Rated Voltage | 0.4kV/1kV(Mainstream Low-Voltage Adaptation, Customizable) |
Rated Current | 200A~2500A(Customizable on Demand,Adapt to Oil-Immersed Transformer Loads) |
Insulation Class | Class A/B(105℃/130℃),Insulation Resistance≥1000MΩ,Oil and Temperature Resistant |
Operating Temperature | -30℃~120℃,Suitable for Oil-Immersed Working Conditions,Excellent Temperature Shock Resistance |
Adaptable Medium | Mineral Insulating oil/Synthetic Transformer oil Oil-Immersed Sealing Without Leakage |
Core Adaptation | Oil-Immersed Distribution Transformers,Power Transformers,Low-Voltage Side Winding Scenarios |
