Product Highlights (Core Simplified)
①Excellent Insulation: Vacuum epoxy casting process, dense insulation layer, low partial discharge, corona resistance and breakdown resistance, suitable for high-voltage operation
②Corrosion & Aging Resistance: Epoxy resin material, waterproof, dustproof and chemical corrosion resistant, no aging or deformation, service life ≥20 years
③Stable Structure: Integral molding design, high mechanical strength, vibration resistance and impact resistance, stable operation without noise
④Wide Adaptability: Standard specifications, voltage and current can be customized on demand, suitable for various 10kV/35kV high-voltage power equipment
⑤Maintenance-Free: Excellent sealing performance, no regular maintenance of insulation layer required, reducing later maintenance costs
Product Details
Core Parameters | Specifications(Core Model) |
Coil Material | Copper Conductor (Oxygen-Free Copper), Insulation Layer:Epoxy Resin(EPOXY) |
Casting Process | Vacuum Epoxy Resin Casting,Bubble-Free, Crack-Free,Integral Molding |
Rated Voltage | 10kV/35kV(Mainstream High-Voltage Adaptation, Customizable) |
Rated Current | 100A~630A (Customizable on Demand,Adapt to Different Loads) |
Insulation Class | ClassH(180℃),Partial Discharge ≤10pC, Excellent Insulation Performance |
Operating Temperature | -40℃~150℃,Resistant to High and Low Temperature Shock .Adapt to Harsh Environments |
Protection Level | IP67,Waterproof, Dustproof,Corrosion- Resistant, Suitable for Outdoor/Humid Scenarios |
Core Adaptation | High-Voltage Transformers,Switchgear, Power Distribution Devices,High-Voltage Scenarios in Power Systems |
