Product Highlights(Core Simplified)
①Low Loss & Energy Saving: CRGO material, low no-load loss, effectively reducing transformer operation energy consumption, meeting energy-saving requirements
②Stable Structure: Full miter joint laminated design, high magnetic permeability, low magnetic leakage, low operation noise (≤55dB)
③High Temperature & Aging Resistance: Class F heat resistance, Class H insulation, long service life, suitable for long-term stable operation scenarios
④Wide Adaptability: Standard size and structure, customizable on demand, suitable for various medium and low voltage distribution and power transformers
⑤Easy Processing & Installation: Burr-free laminations, convenient assembly, low later maintenance cost
Product Details
Core Parameters | Specifications(Core Model) |
Core Material | Cold Rolled Grain Oriented silicon Steel (CRGO),0.30/0.35mm
Thickness(Mainstream Adaptation) |
Core Structure | Laminated Type(EI/CD Type),FullMiter Joint, Bur-Free Treatment |
Rated Flux Density | 1.5~1.7T (Power Frequency 50Hz,Low Los5 Adaptation) |
No-Load Loss | ≤1.2W/kg (Under 50Hz, Rated Flux) |
No-Load Current | ≤1.5%(Under Rated Voltage,Stable No-Load Operation) |
Operating Temperature | -20℃~120℃,Heat Resistance Class F(155℃) |
Insulation Class T | Class H,Encapsulated with High-Temperature Resistant Insulating Paint |
Core Adaptation | Distribution Transformers,Power Transformers,Suitable for Medium and Low Voltage Scenarios |
