Letters/Muzber5

meaning

S

Thee-phase

C

Forming solid casting

(B)

Low voltage foil wound coil

13

Performance level code

□

30-2500kVA

10kV

HV side voltage level

International standard certification:

Complies with international and domestic standards such as
IEC 60076-11 and GB/T 10228-2023,and can provide
certifications such as CQC

Efficient energy-saving label:

Meets the requirements of the EU Ecological Design Directive and the US Energy Star,with a 30%reduction in no-load losses compared to traditional models,helping customers achieve Obtain green subsidies

Customization capability:

Customized voltage(10kV/6KV),frequency  50Hz/60Hz),wiring group,protection level,etc.according to customer needs,suitable for Different national power grid standards

Full lifecycle services:

Provide English operation manuals,24/7 technical support,instllation and debugging guidance to solve customers'worries

Competitive price advantage:

Large scale production reduces costs,with prices 20-30% lower than international brands,while ensuring the same quality

Fast delivery capability:

Standardized production line,regular models can be delivered within 10 days,customized models can be delivered within 15-20 days to meet urgent project requirements（When the quantity is ≤ 50）

parameter

Standard range

Typical value(630kVA)

Rated capacity

30~2500 kVA(standard),up to a maximum of 10000 kVA

630 kVA

Connect groups

Dyn11(preferred),Yyn0 (optional)

Dyn11

short-circuit impedance

4%(30-500kVA)、6-8%（630-2500kVA）

6%

insulation class

B(100℃)-grade/F(120℃)-grade/H(145℃)-grade

H级

cooling method

AN(natural air cooling/AF(forced air cooling)

AN/AF

partial discharge

≤10 pc

≤5pC

noise level

≤55 dB(1 meter distance)

≤52 dB

no-load loss

Increasing by capacity(30kVA:≤ 150W,2500kVA:≤2880W)

≤1070 W

Load loss-grade(30-2500kVA)

B(100℃)-670~16150W
F(120℃)-710~17170W
H(145℃)-760~18450W

≤6400 W
